Sleeve labeling machine SML-150

Characters:

Ø The machine is made of stainless steel and high quality of aluminum alloy, the reasonable, intact frame, it is easy to adjust.

Ø The feet bolt is not needed, easy to move, suitable for different place.

Ø The Shrinkable film roll with adjustable locking gear, can be adjusted according to different roller 5”～10”

Ø The machine can supply for square bottle and round bottle.

Ø Without tools, the driven machinery can be adjusted to meet different bottle size.

Ø Particular inserting label ways, i.e. pressing inserting label, it is reasonable and convenient.

Ø Full automatic feeder, the flat shrinking and tension are adjusted together.

Ø It is assured to low error that there is inspection of rolling label cut.

Ø Particular blade design, blade base can be change by free, changing blade quickly and conveniently.

Ø It is easy to change the central clamping device without any tools.

Ø Oriental rolling label device can be lift synchronal.

Ø The separating bottle screw, oriental belt and conveyor are adjusted synchronal; It is easy and quick to do.

Ø Adopting ANCHUAN Servo motor made in Japan and sensitive photo electricity, to insure the precision of cutting label.

Ø Stainless steel electric controller, adopting Mitsubishi PLC made in Japan.

Ø Adopting advantaged man-machine automatic controlling technology, main component adopts famous brand.

2. Technical parameters:

Ø Capacity:6000～12000bph( Base of length of label:50mm,500ml of bottle)

Ø Label specification:Φ50～Φ90mm

Ø Bottle diameter:Φ50～Φ90mm

Ø Sleeving length:40～150mm

Ø Label thickness:≥0.035mm

Ø Label material: PVC/PET

Ø Motor power:2.5kw(380V,50Hz)

Ø Dimension: 2400×890×2200mm

Ø Weight: about 750kg
